PRODUCT DETAILS

BiPlasma 3D

Bi-Component Moldable Decorative Coating For Floor

Budget Estimation
Starting from
RM 34 per sqft (including installation)
or
Note: This is just a general price estimation. For more details on the pricing please contact us.

BiPlasma 3D is a two-component moldable plastic coating for interior, formulated with special binders, thickeners and inert fillers. Suitable for tiled floors, cement floors and walls (for showers), both small and large surfaces, BiPlasma 3D is indicated for the internal finishing of ancient, modern and classic buildings, commercial establishments, luxury hotels to which you want to confer elegance and decorative originality. It's special formulation makes it seamless, very hard and very durable.

Summary



product

use

dilution (water)

approx. coverage

tool

drying time

colour

Base coat

Super P3D/ Stucco P3D

2 Coats with Fiber Mesh

Ready to use

1 m2/kg

6-8 h

white

Fixative

Primer P3D

1 Coat

Dilute with 5% water

10 m2/L

1-2 h

white

Primer

Intermedial P3D Floor

1 (or 2) Coats

Ready to use

14 m2/L

4-6 h

Coloured

Finish coat

BiPlasma 3D

2 (or 3) Coats

Mix with catalyst and dilute up to 5 % water

6 m2/L

4-6 h

Coloured

Protective coat

Microvetro Bi

2 (or 3) Coats

Mix with catalyst and dilute 10 to 20 % water

5 m2/L

4-6 h

Transparent (Matte, Satin or Glossy)

Please refer to below Step by Step Guide for more details.

Step by Step Guide

Step 1 (Base Coat – Super P3D)

  • Apply at least 2 layers using stainless steel trowel.
  • Insert Fiber Mesh on the first coat while its wet.
  • Apply second coat after first coat is dry.
  • If necessary, apply the third coat.
  • After 6-8 hours, sand with 80/100 sanding paper.
  • Remove any residual dust.

Step 2 (Fixative – Primer P3D)

  • Make sure floor is dustfree.
  • You may dilute Primer P3D Floor with 5% water.
  • Apply the primer using roller.
  • Wait 1-2 hours to dry.

Step 3 (Primer – Intermedial P3D)

  • Intermedial P3D Floor is to be tinted the same colour as BiPlasma base.
  • Intermedial P3D Floor has two types: P/T is for light colours & D/A is for dark colours.
  • Apply Intermedial using roller
  • Wait 4-6 hours to dry

Step 4 (Finishing Coat – BiPlasma 3D)

  • Mix BiPlasma 3D (part A) with the Catalyst (part B) at 10% 1kg of Bi Plasma with 100g of Catalyst.
  • Once catalyzed, add up to 5% water, if necessary.
  • Wait for 2-3 minutes before applying it.
  • After adding Catalyst (part B), please use it within 45 hours.
  • BiPlasma 3D has two types: P/T is for light colours & D/A is for dark colours.
  • Apply the first coat of BiPlasma using stainless steel trowel, spreading the surface evenly
  • After 4-6 hours, apply the second coat and if necessary, the third coat.
  • After 24 hours, sand the floor with 320-500-800-1000 grits until obtaining a semi-gloss floor
  • You may continue to sand with 3000-6000 grits to obtain high polished finish.

Note: It is appropriate to mix different batches of the same color in order to ensure color uniformity during application.

Step 5 (Protective Coat – Microvetro Bi)

  • Mix Microvetro (part A) and Catalyst (part B).
  • After adding Catalyst (part B), please use it within 4-5 hours.
  • Dilute Microvetro with 20% water for the first coat and 10% water for the second coat.
  • Microvetro has 3 types of glossiness: Opaca (Matte), Lucido (glossy) and 30 Gloss (Satin), each with different part B ration.
  • Apply first coat using Roller.
  • Wait for 4-6 hours to apply second coat.

Note: Protection is recommended for floors, shower are and table top. For personal home, you may not need Microvetro for high polished finish sanded up to 6000 grits, to maintain the natural glossiness.

Ideal Temperature of application

20 to 25°C

Relative Humidity for application

<= 50%

Dry Film Thickness

0.5 to 1.5 mm per coat

Touch Dry

2 to 4 hours (at above temperature and humidity conditions)

Completely Dry

12 to 24 hours

Density

1.55 kg/L

pH

7-8

Solid Weight

62%

Strength

40N/mm2

Adhesion

2.7N/mm2

Shelf Life

2 years in original tightly closed containers away from direct sunlight and excessive heat.

Min storage temperature

+5°C (41°F)

Max storage temperature

+30°C (86°F)

  • The product can be colored with L’ANGELO 4OX color system. It is appropriate to mix different batches of the same color in order to ensure color uniformity during application.
  • For a perfect hold of the product on slippery surfaces roughen the surface with specific paper or grinder.
  • A third coat of protective coat is recommended for high traffic commercial area.
  • With the addition of metal powders (BiPlasma 3D Metal) it transforms every surface into a metal that the applicator can shape according to his own creativity to obtain shiny metallic finishes in metallic foil.
